In previous post we looked into Ingress as the front facing entry point for your applications users. In this post, we will look into Bastion as the backdoor entry point for infrastructure administration users.

Currently, all the EC2 instances in my cluster are on public subnet which all of them has public IP address. In order to secure the cluster further, we can move our cluster to a private subnet and setup a Bastion instance as a ‘jump’ server. Bastion will be the only instance on your public subnet and it has access to the cluster. We can easily achieve this setup with kops.

Create New Cluster with Bastion

For creating new cluster, you can run below command and your will get a cluster on private network with a Bastion instance ready:

kops create cluster \
  --name=k8s.blog.taufek.dev \
  --state=s3://k8s.blog.taufek.dev.state \
  --zones=ap-southeast-1a,ap-southeast-1b,ap-southeast-1c \
  --dns-zone=k8s.blog.taufek.dev \
  --topology=private \
  --bastion
  --yes

Then run below commands:

kops update cluster \
  --name kubernetes.taufek.dev \
  --yes \
  --state=s3://k8s.blog.taufek.dev.state

In a minute or so you will have your cluster ready. You could run below command to know the status:

kops validate cluster --state=s3://k8s.blog.taufek.dev.state

Add Bastion to Existing Cluster

For existing cluster, you will need to to edit your cluster object. Run below command to open up your cluster yaml file

kops edit cluster --state=s3://k8s.blog.taufek.dev.state

Edit your cluster yml with following settings. You could get the subnets by running kops create command with dry-run flag and output to a file.

  ...
  subnets:
  - cidr: ...
    name: ap-southeast-1a
    type: Private            # change this to Private
    zone: ap-southeast-1a
  - cidr: ...
    name: ap-southeast-1b
    type: Private            # change this to Private
    zone: ap-southeast-1b
  - cidr: ...
    name: ap-southeast-1c
    type: Private            # change this to Private
    zone: ap-southeast-1c
  - cidr: ...                # add these new Utility subnets
    name: utility-ap-southeast-1a
    type: Utility
    zone: ap-southeast-1a
  - cidr: ...
    name: utility-ap-southeast-1b
    type: Utility
    zone: ap-southeast-1b
  - cidr: ...
    name: utility-ap-southeast-1c
    type: Utility
    zone: ap-southeast-1c
  topology:
    bastion:                 # add bastion entry here
      bastionPublicName: bastion.blog.k8s.taufek.dev
    dns:
      type: Public
    masters: private         # change to private
    nodes: private           # change to private

Then run below to create Bastion instance.

kops create instancegroup bastions \
  --role Bastion \
  --subnet ap-southeast-1a,ap-southeast-1b,ap-southeast-1c \
  --state=s3://k8s.blog.taufek.dev.state

Run below command to push update to your cluster

kops update cluster --yes --state=s3://k8s.blog.taufek.dev.state
kops rolling-update cluster  --state=s3://k8s.blog.taufek.dev.state --yes

That’s all too it, and just wait for few minute for your cluster to be reconfigured with private subnet. And you should also be able to ssh into your Bastion instance with following command:

ssh -A admin@bastion.blog.taufek.dev

Below is how the cluster looks like before, without Bastion:

Cluster without Bastion

And below is how it looks like now, with Bastion:

Cluster with Bastion

One thing that made me hesitated to stick with this setup, is the additional ELBs it created for Bastion and Master instances. This means it will be a significant cost increase in my AWS bill. So I decided to undo this change.

In order to remove Bastion you will need to edit back your cluster yaml file and remove Bastion instance.

Edit your cluster yml with following settings

  ...
  subnets:
  - cidr: ...
    name: ap-southeast-1a
    type: Public             # change this back to Public
    zone: ap-southeast-1a
  - cidr: ...
    name: ap-southeast-1b
    type: Public             # change this back to Public
    zone: ap-southeast-1b
  - cidr: ...
    name: ap-southeast-1c
    type: Public             # change this back to Public
    zone: ap-southeast-1c
  ...                        # remove the Utility subnets
  topology:
  ...                        # remove bastion
    dns:
      type: Public
    masters: public          # change this back to public
    nodes: public            # change this back to public

Run below command to push update to your cluster

kops update cluster --yes --state=s3://k8s.blog.taufek.dev.state
kops rolling-update cluster  --state=s3://k8s.blog.taufek.dev.state --yes

Run below command to remove Bastion instance

kops delete instancegroup bastions  --yes --state=s3://k8s.blog.taufek.dev.state

Conclusions

Bastion is not a concept solely for Kubernetes but it’s a common practice in fortifying your software infrastructure even without Kubernetes. I found that by looking at all the AWS services created by kops, you could learn so much about best practices in software infrastructure. I don’t have much experience in setting up production environment but I learn a lot in past couple of weeks by looking at how kops wires everything together.

You can’t appreciate enough the complexity of services kops utility created under the hood with just one command, kops create .... I can’t imagine the hours you have to put in to setup everything manually versus doing it with kops. And it is just not about creating but also managing the infrastructure with this utility. Not only you save your time but rest assured that your infrastructure is configured in a correct manner.
